www.stryker.com KK-7100 REV 02 1-31
Operation
Installing the bed extender bolster mattress (Continued)
To install the bed extender bolster mattress:
1. See Extending the bed extender (option) on page 1-30.
2. Place the bed extender bolster mattress between the mattress and the footboard.
3. Press down on the bed extender bolster mattress to secure it into place.
Extending or retracting the linen tray (option)
The linen tray is an optional built-in storage unit that can store a patient’s clothes, laundry, or the nurse control pendant.
You can find the linen tray at the foot end of the product.
WARNING
Always retract the linen tray (option) before you put the product in motion.
CAUTION
The safe working load of the linen tray is 15 kg.
To extend the linen tray, grasp the plastic linen tray and pull the linen tray out toward you.
To retract the linen tray, grasp the plastic linen tray and push the linen tray into the frame.
Figure 1-19: Extending or retracting the linen tray
Figure 1-20: Storing the nurse control pendant
Inserting or removing a cassette from the X-ray cassette holder (option)
WARNING
Do not use the product for X-ray procedures if it does not have the radiolucent backrest (option).
The SV1 may include an optional radiolucent backrest to allow X-ray images to be taken while the patient is on the bed.
You can take X-ray images by inserting an X-ray cassette into the housing that is located behind the backrest. You do not
need to move the patient to insert an X-ray cassette or take an X-ray.
