COMPADRE - Dual Voice Compressor & Boost
pg 20
Factory Reset
Restores the pedal to factory power up modes and secondary functions
and replaces all stored presets with the factory defaults.
Sweep the DRY knob from 0-100% and back two (2) times. The
BOOST LED will change colors at the extremes of the knob
range and blink RED to indicate when the reset is taking place.
Turn 1: AMBER
Turn 2: RED
Turn 3: AMBER
Turn 4: Both LEDs flash RED, Compadre resets and restarts
FACTORY SETTINGS
FAV/MIDI Jack: Assigned to FAVORITE mode.
Bypass Mode: Auto Bypass
MIDI channel: 1
MIDI Output Mode: Off
Press and hold the
COMP footswitch while
powering up the pedal.
Once both LEDs flash,
release the footswitch.
1
2
