COMPADRE - Dual Voice Compressor & Boost
pg 7
Power Up Modes – Bypass Mode
Turn the COMPRESSION knob to select one of the options below.
The COMP LED will change color to indicate the current status
as the knob is turned.
True Bypass: GREEN
Auto Bypass: AMBER (default)
True Bypass, but forces Buffered Bypass when Volume Pedal
jack is connected
Buffered Bypass: RED
Press and hold the
COMP footswitch while
connecting power to
the pedal. Once both
LEDs flash, release the
footswitch.
1
2
3
Press the COMP or BOOST
footswitch to store the
bypass mode and begin using
Compadre.
NOTE: Power up modes are
saved unless they are changed
again with the steps above.
NOTE: Auto and Buffered Bypass allow for the Volume Pedal jack
to operate while the pedal is bypassed.
Setting Compadre to Buffered Bypass mode preserves the high
frequency response of your guitar signal through your pedal chain and
long cable runs.
