COMPADRE - Dual Voice Compressor & Boost
pg 5
COMP
Engages and disengages the VCA
compressor independent of the
BOOST. RED LED ON indicates
that the compressor is engaged.
BOOST
Engages and disengages the
variable boost independent
of the COMP. The boost is
post-compression. RED LED
ON indicates that the boost is
engaged.
NOTE: When both BOOST and COMP are disengaged,
the bypass is either Buffered Bypass or True Bypass
depending on the selected mode.
Controls and Connections – Front Panel (cont.)
