Conduit - MIDI Hub
pg 3
Modes Of Operation
Conduit operates in two distinct modes: Standalone and USB MIDI
Interface modes.
Standalone Mode
Conduit always operates in Standalone mode unless it is connected to
a computer via the USB-C port. This mode is used for distributing MIDI
data received at the DIN MIDI IN to the 1/4” TRS jacks and the DIN MIDI
OUT port. A common example of this is connecting a MIDI controller to
the DIN MIDI IN of Conduit which distributes the MIDI data out to the
1/4” TRS jacks and DIN MIDI OUT port.
(See Appendix 1 starting on page 19 for details.)
USB MIDI Interface Mode
Conduit enters USB MIDI Interface mode when it is connected to a
computer via the USB-C port. When USB is connected, Conduit will
expose each of the TRS jacks and the 5-pin DIN pair as an independent
MIDI device.
(See Appendix 2 starting on page 22 for details.)
