pg 7
1/4" TRS Jack Configurations
Out of the box, Conduit’s 1/4" TRS MIDI jacks are configured to work
with Strymon pedals with no further setup necessary. If you are
using Conduit with non-Strymon pedals, you may need to change the
configuration of one or more of the 1/4" TRS jacks.
(See page 8 for details.)
Press the SET button at any time to show the configuration state of all
1/4" TRS jacks:
GREEN = Tip Send (default setting — use for Strymon pedals)
Conduit sends MIDI at the TIP and receives at the RING.
RED = Ring Send
Conduit sends MIDI at the RING and receives at the TIP.
AMBER = Tip and Ring Send
Conduit sends MIDI at both the TIP and the RING.
PURPLE = TRS TYPE A
Conduit sends MIDI OUT only with the RING as the current source
and TIP as the current sink.
NOTE: This mode can be used to connect
two pedals to a single 1/4" TRS jack.
(See page 13 for details.)
NOTE: If you are using Conduit with non-Strymon pedals, visit
strymon.net/support/conduit to find out which 1/4" TRS jack
configuration will work with your specific pedals.
