Stûv 30-compact - installation [en] - 01/13
Removing the exterior parts of the stove (continued)
> Remove the ash pan :
open the ash pan door [photo 7] and
take it out by lifting it off its hinges
[photo 8].
> Remove the doors :
half open them gently [photo 9], lift
them off their hinges and slide them
to the left [photo 10].
