Stûv 30-compact - installation [en] - 01/13
Connection going upwards
Fit the flue onto the top of the stove
and fix it in place using the 3 self-
tightening screws in the 3 holes
provided [photo 1].
Connection to smoke flue
Remarks
If you are going to use a connecting
flue that is all one piece, allow play
of 2mm/m in length to allow for
expansion.
The smoke outlet can accept ducts of
0.4 to 2.0mm in thickness.
It is preferable to use the screws
supplied by Stûv. If not, make sure
that you do not use screws that are
too long and will block the rotation
system.
Accessories for the connection to the smoke flue
Stûv offers a range of accessories for
connecting the Stûv 30-compact to
the smoke flue.
– Recessable wall connector [photo 1],
– Black duct ; straight and bent
[photo 2].
