Stûv 30-compact - installation [en] - 01/13
Tools
Holding capacity of the structure
The stove’s surroundings
Ensure the floor is resistant enough to
support the stove ; consult a specialist
if in doubt.
Prevent "heat traps" in the
cladding, recess and hood
If the stove is situated in a bell-shaped
area (ex : a former hearth), this space
must be ventilated to prevent "heat
traps".
The heat radiated from the glass door
and the walls may be significant.
Whichever direction the stove is
facing, please adhere to the safety
distances from combustible materials
[diagram 1] or ensure that the
materials exposed to radiated heat are
resistant to high temperatures.
