Stuv 30 Compact - Page 4

4
SN 94770 - ...
Stûv 30-compact - installation [en] - 01/13
Other technical characteristics
Stûv 30-compact
Minimum diameter of the duct for the intake of outside combustion air 100cm
2
Maximum length of logs in vertical position 40cm
Maximum length of logs in horizontal position 25cm
System mass 114kg
Optimum output range for usage 3 – 9kW
Range of wood consumption per hour recommended (at 12% humidity) 0.8 – 2.5kg
Maximum limit for consumption of wood per hour
(to avoid overheating the system)
3.3kg/h
glass-door mode
closed-door
mode
open-fire mode
Minimum draught needed to obtain the rated calorific output 12Pa 12Pa 7Pa
Weight-flow ratio of smokes 4.9g/s 4.6g/s 33.6g/s
Average smoke temperature at rated power 325 °C 340 °C 180 °C
Standards, certification and technical characteristics (continued)
