TROUBLESHOOTING
When ignitor button
is pressed in, there
is no spark at ODS/
pilot.
1. Ignitor electrode positioned wrong.
2. Ignitor electrode broken.
3. Ignitor electrode not connected to
ignitor cable.
4.
Ignitor cable pinched or wet.
5. Broken ignitor cable.
6. Bad piezo ignitor.
7. Battery too low.
1. Replace electrode.
2. Replace electrode.
3. Reconnect ignitor cable.
4. Free ignitor cable if pinched
by any metal or tubing.
Keep ignitor cable dry.
5.
Replace ignitor cable.
6. Replace ignitor.
7. Replace battery.
ODS/pilot lights but
ame goes out
when control knob
is released.
1. Gas supply turned off or
equipment shutoff valve closed.
2.
Control knob not fully pressed in
while pressing ignitor button.
3.
Air in gas lines when installed.
4. ODS/pilot is clogged.
5. Control knob not in pilot position.
6. Gas regulator setting is not correct.
1. Turn on gas supply or open
equipment shutoff valve.
2.
Fully press in control knob
while pressing ignitor button.
3. Continue holding down
control knob. Repeat ignit-
ing operation until air is
removed.
4. Clean ODS/pilot (see Care
and Maintenance page 30).
or replace ODS/pilot
assembly.
5. Turn control knob to pilot
position.
6. Replace gas regulator.
PROBLEM POSSIBLE CAUSE
REMEDY
1. Control knob not fully pressed in.
2. Control knob not pressed in
long enough.
3. Equipment shutoff valve not
fully open.
4. Thermocouple connection loose
at control valve.
5. Pilot ame not touching
thermocouple, which allows
thermocouple. This problem could
be caused by one or both of the
following:
a) Low gas pressure.
b) Dirty or partially clogged
ODS/pilot
6. Control valve damaged.
1. Pressed in control knob
fully.
2. After ODS/pilot lights,
keep control knob pressed
in 30 seconds.
3. Fully open equipment
shutoff valve.
4. Hand tighten until snug,
and then tighten 1/4 turn
more.
5.
a) Contact local natural or
propane/ LP gas company.
b) Clean ODS/pilot (see Care
and Maintenance page 30),
or replace ODS/pilot
assembly.
6.
Replace control valve.
When ignitor button
is pressed in, there
is a spark at ODS/
pilot but no ignition.
