Style selections SSD24TR - OPERATION AND MAINTENANCE; Installing Logs

19
INSTALLING LOGS
WARNING: Failure to position the parts in accordance with these diagrams or failure
to use only parts specically approved with this heater may result in property damage
or personal injury.
CAUTION: After installation and periodically thereafter, check to ensure that no yellow
ame comes in contact with any log. With the heater set to High, check to see if
Provided Logs: 7
yellow ames contact any log. If so, reposition
logs according to the log installation instructions
in this manual. Yellow ames contacting logs will
create soot.
It is very important to install the logs exactly as
instructed. Do not modify logs. Use only logs
supplied with heater.
Each log is marked with a number. This number
will help you to identify the logs when installing.
After installing logs, add decorative cinders
around the grate base, do not place any
decorative cinders on logs or burner.
1. Insert log #1 into slots in
rear log bracket on grate
base, and tighten nuts.
Figure 20 - Installing Log #2
Figure 21 - Installing Log #3
Figure 22 - Installing Log #4 Figure 24 - Installing Log #6, and
Log #7
Figure
23 - Installing Log #5
1
2
5
4
3
5. Insert the recessed hole
on the bottom of log #5
onto pin on log #
1, with
the other end placed on
log #4.
5
2
7
4
1
3
6
6. Insert the recessed hole
on the bottom of log #6
onto pin on log #
1, with
the other end placed on
log #3.
Position #7 log on re-
place bottom in front of
controls.
4. Insert log #4 into slots in
front log bracket on grate
base and tighten nuts.
3
4
1
2
1
2
3
3.
Insert log #3 into slots in
front log bracket on grate
base and tighten nuts.
1
2
2. Insert log #
2 into slots in
middle grate bracket and
tighten nuts.
Figure 19 - Installing Log #1
1
18 IN. VENT-FREE GAS LOGS
