Specifications/Fuses
and
circuits
Fuses
and
circuits
&
Fuse
panel
located
in
the
passenger
compartment
Fuse
panel
Fuse
rating
Circuit
1
20A
(Not
available)
2
7.5A
.
Combination
meter
3
15A
.
Door
locking
4
10A
.
Front
wiper
deicer
relay
5
Empty
6
7.5A
.
Remote
control
rear
view
mirrors
.
Seat
heater
relay
7
10A
.
Combination
meter
.
Integrated
unit
8
7.5A
.
Stop
light
9
7.5A
.
Front
wiper
deicer
10
7.5A
.
Power
supply
(battery)
1
1
7.5A
.
Turn
signal
unit
12
15A
.
Transmission
control
unit
.
Engine
control
unit
.
Integrated
unit
13
20A
.
Accessory
power
outlet
(center
console)
14
10A
.
Parking
light
.
T
ail
light
.
Rear
combination
light
12-10
544
546
