Suffolk C-type - RDH Brake Pipe Locations & Sizes

14
C-type - RHD Brake/Fuel Pipes Locations & Sizes
(XJ6 Master Cylinder and optional servo)
FRONT SECTION
CODE
DESCRIPTION
LENGTH
THREAD
UNION
FLARE
F1
MASTER CYLINDER TO
SERVO or DIRECT TO
3-WAY BRAKE SWITCH
CONNECTOR IF NOT USING
SERVO.
8”
10mm LATE TYPE
MASTER CYLINDER
7/16 EARLY TYPE
MASTER CYLINDER
3/8 UNF
MALE
MALE
MALE
SINGLE
SINGLE
SINGLE
F2
SERVO TO 3-WAY BRAKE
SWITCH CONNECTOR
9 ½”
3/8” UNF
3/8” UNF
MALE
MALE
SINGLE
SINGLE
F3
3-WAY BRAKE SWITCH
CONNECTOR TO FRONT 3-
WAY CONNECTOR
26”
3/8” UNF
3/8” UNF
MALE
MALE
SINGLE
SINGLE
F4
FRONT 3-WAY CONNECTOR
TO N/S FRONT
20”
3/8” UNF
3/8” UNF
MALE
FEMALE
SINGLE
DOUBLE
F5
FRONT 3-WAY CONNECTOR
TO O/S FRONT
9”
3/8” UNF
3/8” UNF
MALE
FEMALE
SINGLE
DOUBLE
EXTRAS:
5no. 3/16” P-clips with self tapping screws
REAR SECTION
CODE
DESCRIPTION
LENGTH
THREAD
UNION
FLARE
R1
MASTER CYLINDER TO
REAR DIFF FLEXI HOSE
65”
3/8 EARLY TYPE
MASTER CYLINDER
12mm LATE TYPE
MASTER CYLINDER
3/8” UNF
MALE
FEMALE
SINGLE
DOUBLE
R2
REAR 3-WAY CONNECTOR
TO L/H SIDE OF CAR
50”
3/8” UNF
3/8” UNF
MALE
MALE
SINGLE
SINGLE
R3
REAR 3-WAY CONNECTOR
TO R/H SIDE OF CAR
18”
3/8” UNF
3/8” UNF
MALE
MALE
SINGLE
SINGLE
R4
REAR CALIPER LOOP PIPE
X2
11 ½”
3/8” UNF
3/8” UNF
MALE
MALE
SINGLE
SINGLE
EXTRAS:
5no. 3/16” P-clips with self tapping screws
5no. 3/16” P-clips with 5/16” securing holes and 2no. 5/16”unf x 3/4 hex head, nuts, washers
FUEL PIPES
CODE
DESCRIPTION
LENGTH
CODE
DESCRIPTION
LENGTH
FP1
MAIN METAL PIPE
1700MM
FP5
FILTER TO WEBERS
600MM
FP2
TANK TO PUMP
400MM
FP6
WEBER LINKS X2
165MM
FP3
PUMP TO REAR OF FP1
840MM
FP7
FILTER TO SU ‘T PIECE’
450MM
FP4
FRONT OF FP1 TO FILTER
250MM
FP8
‘T PIECE’ TO SU’S X2
250MM
EXTRAS:
6no. 5/16” P clips with self tapping screws
4no. 5/8” P clips with bolts, nuts, washers
