Section 7
ILLUSTRATIONS AND PARTS LIST
51
7.4B RADIATOR & COMPRESSOR FLUID SYSTEM -- 185 & 185H MODELS
key part
number description number quantity
1 guard, fan 20” x 2---3/4” 185q 250003---882 1
2 bracket, oil filt mtg 100---125 250018---632 1
3 grommet,rubber 1” dia x 1/4” 250023---395 2
4 clamp, hose 1---5/16 to 2---1/4adj 040014 2
5 washer, pl b r 1/4” 837204---071 2
6 capscrew, hex hd 1/4 x 1 828604---100 2
7 nut,hex flanged 5/16 825305---283 10
8 screw, hex serr 5/16---18 x 1 829705---100 2
9 hose, hydraulic 3/4” x 30” 250020---338 1
10 screw, ser wash 5/16x3/4” 829705---075 12
11 hose,med press .75 x 72” 249612---013 1
12 hose,med press .75 x 40” 249612---022 1
sub assembly,cooler/rad. 185---2w (I) 250040---044 1
14 radiator,175---250q 02250050---542 1
Scap, radiator 040140 1
15 baffle, cooler curbside 175---250q 02250050---543 1
16 cooler, oil tip down 175---185 02250045---117 1
17 baffle, cooler streetside 175---250q 02250050---544 1
18 hose,rad. up 185 jd 250004---126 1
19 hose,rad. low 185 jd 250004---127 1
20 shroud, fan 185 jd 250005---179 1
21 sleeve, 1/8” cable .575” lg 241381 2
22 grommet,1.5id x 2---1/8od x1.75 250020---358 2
23 clamp, hose 1---5/16 to 2---1/4adj 040014 2
24 weatherstrip, 1”thk x 1”wide (ft) 250041---174 3
25 cable,plastic coated 1/16”---ft 241380 2
26 drainlock, 1/4” 040061 1
27 clamp, wire 043194 1
28 washer, pl b r 3/8” 838206---071 2
29 screw, ser wash 5/16x3/4” 829705---075 2
30 hex hd. serr 5/16 x 1/2 829705---050 8
31 nut,hex flanged 5/16 825305---283 2
32 capscr, hex gr5 1/4---20 x .75 lg 829104---075 4
(Continued on Page 53)
(I) Consists of Items #14 through #35.
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
