Section 7
ILLUSTRATIONS AND PARTS LIST
55
7.5 FRAME, AXLE & PARTS & AXLE ASSEMBLY (Exploded View) -- ALL MODELS
key part
number description number quantity
1 frame assy, 175---250 02250054---697 1
2 drawbar, 100---185q adjust hitch 250039---545 1
3 bail,lifting 175/185q 250027---089 1
4 adapter, jack/drawbar 100---185 250040---851 1
5 jack, screw mtg swvl 250040---854 1
6 bracket, spring hanger front 250002---071 2
7 bracket, spring hanger rear 250002---070 2
8 eye, 3” lunette 250002---221 1
9 axle, assembly 3500# 46”tr x 31”sc 02250054---698 1
10 tire,assembly f78---14(c) 02250048---334 2
11 link, quick 5/16” 250017---836 1
12 chain, 3/8” x 71” w/2 hks pltd 250018---492 1
13 plug,plastic 1” dia 234114 3
14 baffle, tool box 185 250022---889 1
15 capscrew, hex gr8 5/8---11 x 4---3/4” 828210---475 2
16 washer, lock reg 1/2” 837508---125 13
17 capscrew, hex gr5 7/16---14 x 1” 828607---100 4
18 nut,hex locking 7/16 825507---223 4
19 capscr, hex gr8 1/2---13 x 1.25 828208---125 16
20 nut,hex locking 5/8 825510---329 2
21 capcsr, hx gr8 1/2---13 x 1---1/2 828208---150 5
22 washer, pl, b r 1/2” 837208---112 5
23 screw, ser wash 5/16x3/4” 829705---075 2
24 nut,hex flanged 5/16 825305---283 2
25 screw, hexagon hd 5/16---24 x 1/2” lg 02250049---367 1
26 nut,hex jam rh unfin 5/16---24 824605---195 1
27 nut,hex locking 1/2 825508---262 8
28 washer, pl---b wide pltd. 7/16” 838307---112 4
kit,hdwr 175---185 running gear (not shown) 250002---968 1
30 link, shackle 3.12” long 242215 4
31 bolt, shackle frmn #46649 047885 6
32 nut,shackle bolt frmn #46650 047886 6
key part
number description: axle assembly number quantity
33 axle, beam 3500# 250040---791 1
34 U---bolt 242048 4
(Continued on Page 57)
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
