7.5 FRAME, AXLE & PARTS & AXLE ASSEMBLY (Exploded View) -- ALL MODELS (Continued)
key description: axle assemb ly part
number (continued) number quantity
35 fitting, grease 861000---025 2
36 seal, grease 250040---783 2
37 bearing, inner 250023---467 2
38 hub, wheel 5” x 4 1/2” 250023---469 2
39 stud, wheel 1/2”---20 250023---468 10
40 nut, wheel 1/2”---20 250023---470 10
41 cap, grease 250040---785 2
42 plug, rubber 250040---786 2
43 nut, spindle 040122 2
44 washer, spindle 047874 2
45 bearing, outer 250023---466 2
46 plate, tie 045197 2
47 nut, U---bolt 1/2”---20 047881 8
48 spring, underslung 02250051---990 2
49 washer, tang 250040---784 2
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
