Section 7
ILLUSTRATIONS AND PARTS LIST
63
7.6B RECEIVER, PNEUMATIC CONTROL & SERVICE VALVE ASSEMBLY -- 185H MODELS
key part
number description number quantity
1 bracket, receiver mounting 250002---575 1
2 sub assembly,sight glass 600---1600 02250054---518 1
3 insert,nyl tbg 1/4 od x .035w 02250052---841 2
4 silencer, air ejection 248755 2
5 orifice,.078” x 1/8 fnpt x 1/8 mnpt 02250069---264 1
6 tee,male 1/4t x 1/4p 250028---582 1
7 elbow, 1/4”tube x 1/4”npt 250018---430 6
8 nipple,pipe hx 1/ 4” 860404---025 2
9 washer,nylon shoulder .616/.515 02250058---404 1
10 connector,1/4” tube x 1/8” npt 250018---427 2
11 valve,3---way toggle 02250057---083 1
12 nipple,pipe 1---1/2 x 3.5 sc 40 822124---035 1
13 tube,nyl .25 od x .040w blk 02250054---861 11
15 bushing,red 1/4x1/8 807600---005 1
16 cross, pipe 150# 1/4 801315---010 1
17 tube,nyl .25 od x .040w wht (ft) 02250054---860 3
18 capscrew, hex gr8 3/8---16 x 1---1/4” 828206---125 6
19 washer, pl b r 3/8” 837206---071 6
20 washer, lock reg 3/8” 837506---094 4
21 nut,hex locking 3/8 825506---198 2
sub assembly,receiver 185h (I) 02250071---583 1
23 receiver, air/oil sep. 185q 250002---077 1
24 valve, min. pressure check (II) 241581 1
25 sub assembly,service valve 175---250 jd 02250061---690 1
26 sub assembly,blowdown pneu. controls 02250061---997 1
27 connector, flex 1/4t x 1/4” 020169 1
28 tube,stl1/4”od oil siphon 185 250004---043 1
29 tee, reducing 1 1/ 2 x 1/2 x 1 1/2 802206---026 1
30 connector, tube---m 1/4 x 1/4” 812204---025 1
31 strainer, v---type 300psix1/ 4 (III) 241771 1
32 connector,1/4” tube x 1/4” npt 250018---428 1
(Continued on Page 65)
(I) Consists of Items # 23 through # 43.
(II) For maintenance on minimum pressure check valve no. 241581, order repair kit no. 001177.
(III) For maintenance on strainer no. 241771, order repair kit no. 241772.
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
To Next Page
