Section 7
ILLUSTRATIONS AND PARTS LIST
65
7.6B RECEIVER, PNEUMATIC CONTROL & SERVICE VALVE AS SEMBLY -- 185H MODELS (Continued)
key part
number description number quantity
33 valve, relief 1/2” 175 psi 409955 1
34 hose, h ydraulic 1---1/2 x 37.5”mm1.75# 040291 1
35 element, sep 185p bulk 02250078---029 1
36 hose, hydraulic 3/4 x 30” 250020---338 1
37 sub assembly,regulator valves 02250058---204 1
38 nipple,pipe 1 x 7.0 sc 80 822216---070 1
39 nipple,pipe 1---1/4 x 2.5 sc 80 822220---025 1
40 bushing,red 1---1/4 x 1 807605---040 1
41 elbow, pipe 3/4 45 d 801415---030 1
42 plug, pipe 3/8 steel 807800---015 1
43 plug, pipe 1/8 steel 807800---005 1
key part
number description: service valve assembly number quantity
1 valve, dual outlet 1” x 3/4” 250019---916 1
2 nipple,pipe 1 x cl sc 80 822216---000 1
3 elbow, pipe 1 300# 806530---040 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
