Section 7
ILLUSTRATIONS AND PARTS LIST
67
7.7 REGULATOR VALVE ( 175 & 185 ) & RECEIVER FLUID FILL ASSEMBLIES -- ALL MODELS
key part
number description: regulator valve assembly number quantity
1 tee,male 1/4”t x 1/4”p 250028---582 1
2 nipple,pipe hx 1/ 4” 860404---025 1
3 elbow, 1/4” tube x 1/4” npt 250018---430 1
4 valve, pressure regulator (I) 250017---280 1
5 orifice, .093 .125 x .125 250014---060 1
6 silencer, air ejection 248755 1
7 tee,s traight 1/4 802415---010 2
8 nipple,pipe 1/4 x cl sc 80 822204---000 2
9 bushing,red 1/4x1/8 807600---005 1
description: receiver fluid fill
1 glass, oil level sight 1---1/2” 040279 1
2 tee,s traight 1---1/2 802415---060 1
3 adapter, filler 020044 1
4 plug,o---ring 1---1/4” 040029 1
(I) For maintenance on regulator valve no. 250017---280, order repair kit no. 250019---453.
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
