Section 7
ILLUSTRATIONS AND PARTS LIST
69
7.8 BLOWDOWN PNEUMATIC CONTROLS ( 175 & 185 MODELS) & REGULATOR VALVE
ASSEMBLY (185H MODELS)
key blowdown pneumatic controls part
number description number quantity
1valve,blowdown1/4npt(I) 250025---655 1
2 elbow, 1/4” tube x 1/4” npt 250018---430 1
3 orifice, .093 x .125m x .125f 250014---060 1
4 silencer, air ejection 248755 1
5 connector,1/8” tube x 1/8mnpt/str 250038---121 1
6 nipple,pipe hx 1/ 4” 860404---025 1
7 tee,s traight 1/4 802415---010 2
8 nipple,pipe 1/4 x cl sc 80 822204---000 1
9 bushing,red 1/4x1/8 807600---005 2
10 nipple,pipe 1/4 x 1.5 sc 80 822204---015 1
key regulator valve assembly part
number description number quantity
1 elbow, 1/4” tube x 1/4” npt 250018---430 3
2 valve, regulator back press. (II) 041517 1
3 valve, pressure regulator (III) 250017---280 1
4 nipple,pipe 1/4 x cl sc 80 822204---000 3
5 cross, pipe 150# 1/4 801315---010 1
6 plug, pipe 1/4 s teel 807800---010 1
(I) For maintenance on blowdown valve no. 250025---655, order repair kit no. 250031---772.
(II) For maintenance on regulator valve no. 041517, order repair kit no. 041742.
(III) For maintenance on regulator valve no. 250017---280, order r epair kit no. 250019---453.
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
