Section 7
ILLUSTRATIONS AND PARTS LIST
75
7.10 INSTRUMENT PANEL & PARTS -- ALL MODELS
key part
number description number quantity
1 support,inst. pnl. 100---375 02250054---084 1
2 screw, mach. hx #8---32 x 3/4 830101---075 4
3 washer, pl---b reg pltd 1/4” 838204---071 4
panel, assembly inst pnl (I) 02250054---389 1
5 panel,inst. 100---375 g & d 02250053---411 1
6 decal,inst. pnl. 100 thru 375 02250051---277 1
7 isolater, vibration grommet 02250054---081 4
8 switch, star ter 040038 2
9 lamp,warning indicator---amber 02250054---392 1
10 breaker,curcuit 7 amp 250035---353 1
11 hourmeter,12---24 vdc 10000 hr 2” 02250050---517 1
1 2 v a l v e , a u t o w a r m --- u p (II) 250032---545 1
13 gauge,pressure air 0---300 2” 02250044---361 1
14 harness, wire inst pnl 100---375 02250053---590 1
15 plate, face on/off 250017---569 1
16 switch, on/off toggle 250017---556 1
17 switch, pressure selector (185H) 02250057---083 1
18 washer, nylon shoulder (185H) 02250058---404 1
19 decal, high (185H) 249892 1
20 decal, low (185H) 249893 1
21 conn, female 1/8 npt x 1/ 8 tube 250031---503 1
22 tube, nyl .013 od x .017 blk 250038---120 4
(I) Consists of Items #5 through #16.
(II) For maintenance on warm---up valve no. 250032---545, order repair k it no. 250032---891.
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
