Section 7
ILLUSTRATIONS AND PARTS LIST
79
7.11B AIR INLET AND EXHAUST -- 185 & 185H MODELS
key part
number description number quantity
1 elbow, rubber 90 deg 3” 040599 1
2 filter, air 175/250 dpq(I) 250040---807 2
3 duct,aluminized stl 3”od x 20 250005---954 1
4 elbow, rubber 45 deg 3” 041960 2
5 duct,aluminized stl 3”od x 24 250005---272 1
6 hose, hump 3” 042121 1
7 elbow, 90 deg red 2---1/2” x 3” 250032---462 1
8 duct,aluminized stl 3”x 14 250009---754 1
9 tube assembly, engine exhaust 4039 02250052---059 1
10 muffler, exh. res. 185 250020---726 1
11 baffle, front street side 250021---385 1
12 clamp, exh. 2---1/2” 250004---198 1
13 band, mounting 6---1/2” 043370 2
14 raincap,2---3/8 to 2---9/16 045344 1
15 gasket, exhaust jd t20141 046781 1
16 clamp, exhaust jd t---19978 046780 2
17 clamp, hose 2---13/16” to 3---3/4” 250018---550 10
18 washer, pl b r 3/8” 838206---071 8
19 nut,hex locking 3/8 825506---198 8
20 nut,hex flanged 5/16 825305---283 10
21 screw, ser wash 5/16x3/4” 829705---075 8
22 screw, hex ser wash 5/16 x 1 1/2” 829705---150 2
(I) For maintenance on air filter no. 250040---807, order element repair kit no. 02250044---537.
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
