Section 7
ILLUSTRATIONS AND PARTS LIST
81
7.12 FUEL TANK & CONNECTIONS -- ALL MODELS
key part
number description number quantity
1 tank, fuel plastic 25 gal. 02250045---288 1
2 connector, hose 1/4” 043258 1
3 channel, fuel tank support 175---185q 02250044---500 2
4 weat herstrip, 3/16 x 3/8 (ft) 250022---436 5
5 support, fuel tank plastic 175---185 02250044---501 1
6 neck,fuel fill #5 02250047---398 1
7 plug,hex h ead 1---1/2” mpt 02250053---416 2
8 tube assembly, fuel pickup 175---185 02250050---023 1
9 gasket,fuel fill neck 02250047---399 1
10 cap, fuel 2.28 dia. plastic 02250047---397 1
11 elbow, mpt x hose barb 3/8x1/4 02250056---927 1
12 screw,#6---19 x 5/8 phil trus hd 02250064---285 6
13 capscr, hex gr8 1/2---13 x 1.25 828208---125 4
14 washer, sprlock reg 1/2” 837508---125 4
15 washer, pl, b r 1/2” 837208---112 4
16 screw, hex ser wash 5/16 x 1 1/2” 829705---150 2
17 washer, pl---b reg pltd 5/16” 838205---071 2
18 clamp, hose 3/8” 047235 4
19 hose,fuel line 1/4” (ft) 842315---025 2
20 hose,fuel line 5/16” (ft) 842315---031 2
PLEASE NOTE: WHEN ORDERING PARTS, INDICA TE SERIAL NUMBER OF COMPRESSOR
