SECTION 2 TS20C USER MANUAL
31
Figure 2-10: TS20C Piping and Instrumentation 200-250HP
NOTES:
1. PART NUMBERS ARE FOR REFERENCE ONLY. REFER TO BILL
OF MATERIAL AND OR FACE OF ORDER FOR ACTUAL PARTS.
2. SECTION BETWEEN LETTERED POINTS ARE TO BE REPLACED
WITH CORRESPONDING OPTION PICTURED BELOW, AS
REQUIRED BY FACE OF ORDER.
3. CONTROL/MOISTURE DRAIN LINES ARE 1/4" TUBING EXCEPT
AS NOTED.
4. OPTIONAL HEAT TRACE IS APPLIED ONLY TO CONTROL AND
MOISTURE DRAIN LINES AND USED ONLY WITH STAINLESS
STEEL TUBING. REFER TO FACE OF ORDER FOR HEAT TRACE
REQUIREMENTS.
5. PART VARIES BY MODEL.
6. REQUIRED FOR 150# & 175# APPLICATIONS ONLY.
7. TO BE DISCONNECTED FOR DRY PRESSURE TESTING.
PLEASE NOTE: WHEN ORDERING PARTS,
INDICATE SERIAL NUMBER OF COMPRESSOR
RELIEF VALVES
PART # DESCRIPTION
410103 VALVE,RELIEF 1-1/4” NPT 175#
02250049-001 VALVE,RELIEF 1” NPT 210#
FLUID/AIR SEPARATOR TANKS
PART # DESCRIPTION
02250174-146 TNK,FLUID/AIR 20” DIA. SAE PORTS 175# ASME
02250174-147 TNK,FLUID/AIR 20” DIA. SAE PORTS 210# ASME
COMPONENT DESCRIPTION
P1 WET SUMP PRESSURE
P2 LINE PRESSURE
P3 INJECTION FLUID PRESSURE
P4 HIGH PRESSURE SIDE OF FILTER
PSW1 INLET FILTER VACUUM SWITCH
T1 WET DISCHARGE TEMPERATURE
T2 DRY DISCHARGE TEMPERATURE
T3 INJECTION FLUID TEMPERATURE
T4 INTERSTAGE AIR/FLUID TEMPERATURE
T6 FLUID COOLER OUT TEMPERATURE (VSD FAN)
SOL 1 LOAD/UNLOAD SOLENOID VALVE
SOL 3 START CONTROL SOLENOID VALVE
SOL 4 SEQ/SPIRAL CONTROL SOLENOID VALVE
SOL 5 ELECTRIC DRAIN/JZL DRAIN SOLENOID VALVE
SOL 7 EES SOLENOID VALVE
