Spare Parts List 7-1
SummaCut D500 SPARE PARTS
End of Manufacture: MAY, 1996
Part no Description
384-751 Assy LCD module
391-198 Pulley 24 tooth + setscrew
391-200 Assy drag head
391-312 Roller assy
391-318 Media sensor rear assy
391-319 Media sensor front
391-320 Fan assy
391-326 Assy pinch roller
391-342 Assy switch pinch roller
391-344 Assy motor
391-346 Assy, power entry module
391-386 Cutting strip with tape
391-463 Keyboard
391-510 Set of core holder
391-553 Drum
391-555 Belt assy
391-557 Assy drag board
391-759 Antistatic brush
391-935 Assy final control board
421-282 End cover right
421-283 End cover left
423-155 Serial interface cable
MB0380 Belt MXL 150T80
MB9124 Belt MXL 110T80
MW9987 ROM lo (rev 010) old board
MW9988 ROM hi (rev 010) old board
Spare Parts List 7-1
