Service Manual SummaSign series Cutters
SYSTEM TESTS
The SYSTEM TESTS menu is a special set of procedures which are not required for
normal cutter operation. Field service personnel, however, will use the SYSTEM
TESTS menu occasionally. When in SYSTEM TESTS, the cutter is fully operational
and performs as described in this manual.
LANGUAGE
The MENU LANGUAGE submenu is used to set or modify the dialogue language on
the LCD. Press the
or jogging key until the desired language is displayed on
the LCD and press
to confirm.
The information on the LCD can be displayed in English, French, German, Dutch,
Spanish or Italian.
ROM REVISION
Selecting the ROM REVISION option, by pressing the
key will furnish the details
on the cutter’s ROM revision. This information is often helpful to technicians when
diagnosing problems over the telephone.
SERVICE PLOT
The SERVICE PLOT provides information about the cutter, which is helpful when
requesting service for your cutter. The SERVICE PLOT is always plotted at the same
size and should be performed with a pen on paper.
The plot shows the cutter model number, the revision numbers of the installed ROM
(Read Only Memory) circuits, the selected baud rate, the resolution and buffer
(memory) size.
CAUTION
The following test routines are normally restricted to CalComp Field Service
Personnel.
Keyboardcontrols 1-27
