Introduction
Rear
1. Power port Connect the power cord for your monitor to the power port on the
back of the monitor.
2. Signal port Connect the signal cable to the 15-pin D-sub connector on the back
of your monitor.
3. BNC Connectors Connect the signal cable to the BNC signal port on the back of your
monitor.
Note: See Connecting Your Monitor for further information regarding cable connections.
12
3
