EM6910 Café Series Espresso Machine Issue: A Page 14 of 48
• During the event of any of the heater block going open circuit, the unit
shall not be prevented from going into ready mode when the second
thermal block reaches ready temperature.
Figure 3 - LED Ready Mode Pattern
• If either “Manual”, “One Cup”, “Two Cups” buttons is activated during ready
mode, the other remaining two LED’s shall be switched OFF, while the
goes to the user set function. The function setting is stated below: -
• Manual Coffee Function
Coffee water pump shall be switched ON for 2 minutes to pump
water through the coffee brewing outlet. Refer to figure 4 for LED
pattern illumination.
Figure 4
• One Cup Coffee Function
A set amount of one cup of coffee will be automatically produced.
Refer to Section 7.10 for set volume amounts. Refer to figure 5 for
LED pattern illumination.
Figure 5
• Two Cups Coffee Function
A set amount of two cups of coffee will be automatically produced.
Section 7.10 for set volume amounts. Refer to figure 6 for LED
pattern illumination.
Figure 6
