SUNFAR Self-Defined Communication Protocol 85
E500 Series Universal Low-Power Inverter
Data feedback: No. 0 inverter receives data in normal condition.
Slave
machine
response
Frame
header
Slave
address
Slave
response
Status
feedback
0
Monitoring
item
Operating
data
Checksum
Frame
end
Number
of bits
1 2 1 2 1 2 4 4 1
Example
2A 30 30 30 30 31 30 30 30
30 30
36 34
30 32
34 42
0D
5A 00 00 00 00 01 00 00 00
00 00
00 64
00 00
00 65
0D
Descrip-
tion
Frame
header
No.0
slave
machine
response
Slave
machine
receives
data
FWD
running
of slave
machine
Fixed
Data
Current
displayed
monitoring
d-0
Successful
data
setting
Hexadecimal
accumulation
Frame
end
1.4.6 Modify EPROM parameters (Command classification 5)
Data sending: Modify torque boost [F0.11]=6.0, stop and store.
Main
machine
sending
Frame
header
Slave
address
Command
type
Operating
command
Data
classifi-
cation
Data
subentry
Setting
data
Checksum
Frame
end
Number
of bits
1 2 1 2 1 2 4 4 1
Example
2A 30 30 35 30 31 30 30 41
30 30
33 43
30 32
36 44
0D
5A 00 00 05 00 01 00 00 0B
00 00
00 3C
00 00
00 4D
0D
Descri-
ption
Frame
header
Address
00
Command
#5
FWD
running
of slave
machine
F0
Parameter
group
F0.11
Parameter
Data
setting
Hexadecimal
accumulation
Frame
end
Data feedback: Slave machine receives data normally.
Slave
machine
response
Frame
header
Slave
address
Slave
response
Status
feedback
Data
classification
Data
address
Setting
data
Checksum
Frame
end
Number
of bits
1 2 1 2 1 2 4 4 1
Example
2A 30 30 30 30 31 30 30 41
30 30
33 43
30 32
36 38
0D
5A 00 00 00 00 01 00 00 0B
00 00
00 3C
00 00
00 48
0D
Descrip-
tion
Frame
header
No.0
slave
machine
response
Slave
machine
receives
data
FWD
running
of slave
machine
F0
Parameter
group
F0.11
Successful
data
setting
Hexadecimal
accumulation
Frame
end
