(continued from previous page)
void setup() {
...
//ultrasonic
pinMode(echoPin, INPUT);
pinMode(trigPin, OUTPUT);
}
2. First read the distance value obtained from the ultrasonic module, if the distance is greater than 25, let the car
move forward; if the distance is between 2-10cm, let the car move backward, otherwise (between 10~25) stop.
void loop() {
float distance = readSensorData();
if (distance > 25) {
moveForward(200);
}
else if (distance < 10 && distance > 2) {
moveBackward(200);
} else {
stopMove();
}
}
3. About readSensorData() function.
The transmitter of the ultrasonic module transmits a 10us square wave signal every 2us, and the re-
ceiver receives a high level signal if there is an obstacle within the range. Use the pulseIn() function
to record the time from sending to receiving, divide by the speed of sound 340m/s, and then divide
by 2, the result is the distance between this module and the obstacle with units: cm.
float readSensorData() {
digitalWrite(trigPin, LOW);
delayMicroseconds(2);
digitalWrite(trigPin, HIGH);
delayMicroseconds(10);
digitalWrite(trigPin, LOW);
float distance = pulseIn(echoPin, HIGH) / 58.00; //Equivalent to (340m/
˓→s*1us)/2
return distance;
}
• pulseIn(pin, value)
– pin: the number of the Arduino pin on which you want to read the pulse. Allowed data types:
int.
– value: type of pulse to read: either HIGH or LOW. Allowed data types: int.
Reads a pulse (either HIGH or LOW) on a pin. For example, if value is HIGH, pulseIn() waits for
the pin to go from LOW to HIGH, starts timing, then waits for the pin to go LOW and stops timing.
