SunFounder 3in1 Kit
When this function is called, have the LED repeat the toggle from on-off three times so that you see
the LED blink 3 times.
void blinkLED() {
for (int i = 0; i < 3; i++) {
digitalWrite(ledPin, HIGH);
delay(50);
digitalWrite(ledPin, LOW);
delay(50);
}
}
5.11 10. One Touch Start
In this project, we have integrated the previous projects - line following, following, obstacle avoidance, self-driving, etc.
together. They can be switched by buttons on the remote control, so you can start the car and experience all functions
at once.
Wiring
Code
Note:
• Open the 10.one_touch_start.ino file under the path of 3in1-kit\car_project\10.one_touch_start.
• Or copy this code into Arduino IDE.
5.11. 10. One Touch Start 261
