• 0A & OB(B): Output pins of Motor B.
• VCC: Power input pin (2.5V-12V).
• GND: Ground pin.
Features
• On-board 2 L9110S motor control chip
• Dual-channel motor control.
• Independent motor spinning direction control.
• High current output (800mA per channel).
• Wide voltage range (2.5V-12V).
• Compact design.
• Convenient input and output terminals.
• Built-in protective features.
• Versatile applications.
• PCB Size: 29.2mm x 23mm
• Operating Temperature: -20°C ~ 80°C
• Power-On LED indicator
Operating Principle
Here is the truth table of Motor B:
This truth table shows the different states of Motor B based on the values of input pins B-1A and B-1B. It indicates the
direction of rotation (clockwise or counterclockwise), braking, or stopping of Motor B.
B-1A B-1B The state of Motor B
1 0 Rotate clockwise
0 1 Rotate counterclockwise
0 0 Brake
1 1 Stop
Here is the truth table of Motor A:
This truth table shows the different states of Motor A based on the values of input pins A-1A and A-1B. It indicates the
direction of rotation (clockwise or counterclockwise), braking, or stopping of Motor A.
A-1A A-1B The state of Motor B
1 0 Rotate clockwise
0 1 Rotate counterclockwise
0 0 Brake
1 1 Stop
