SunFounder 3in1 Kit
You can also buy them separately from the links below.
COMPONENT INTRODUCTION PURCHASE LINK
Arduino Uno R4 Minima -
Jumper Wires
L9110 Motor Driver Module -
Centrifugal Pump -
Schematic
Wiring
L9110S R4 Board Motor
VCC 5V
GND GND
B-1B 9
B-1A 10
OA one wire of the motor
OB one wire of the motor
4.1. 1. Digital Write 95
