1 InstallationandConnection
1.1 Connecting the eShow to the Inverter
The eShow is installed onto the inverter by means of the bracket and the M4 screw
in the packaging.
Fig. 1-1 Dimensions of the Bracket (unit: mm)
Fig. 1-2 Dimensions of the Fastener (unit: mm)
