Product Description
3.1 System Overview
The MV Station is mainly applied to large-and-medium PV power station. The MV Station
can meet the modular design and quick installation requirements of the large-and-medium
PV power station and can ensure the long-term, reliable, and safe power generation
compliant with the grid.
MV Station is a booster device used in conjunction with the inverters. The main function is to
convert the low-voltage from the inverters into medium-voltage and feed into the grid.
The MV Station integrates LV cabinet, MV transformer, MV switchgear, power distribution
cabinet ,communication box and auxiliary transformer.
The PV power generation system with the MV Station is shown in the following figure.
