43
step 5 Check for polarity correctness.
- - End
5.6.3 Installing the PV Connectors
step 1 Rotate the DC switch to "OFF" position.
step 2 Check the cable connection of the PV string for polarity correctness and ensure that the
open circuit voltage in any case does not exceed the inverter input limit of 1,100 V.
step 3 Connect the PV connectors to corresponding terminals until there is an audible click.
User Manual 5 Electrical Connection
