SunStar KM-2522 Series - Chief Technical Specifications

주요 기계 사양3.
CHIEF TECHNICAL SPECIFICATIONS
모델 KM-2522A KM-2522B KM-2522BL
용도 박물 중물~중물후물~후물
최고 속도 5,000spm 4,000spm 3,500spm
최대 땀수 5mm 7mm 7mm
노루발
상승량
손최대5.5mm( ) 최대5.5mm( ) 최대5.5mm( )
무릎 최대13mm( ) 최대13mm( ) 최대13mm( )
사용 바늘 DB x 1 #9~#18 DB x 5 #16~#23 DB x 5 #16~#23
사용 오일 10# White Oil 10# White Oil 10# White Oil
사용 모터 220V / 550W 220V / 550W 220V / 550W
Model KM-2522A KM-2522B KM-2522BL
Application
Thin-middle thick
materials
middle thick-thick
materials
Thick materials
Max sewing
speed
5,000spm 4,000spm 3,500spm
Max stitch
length
5mm 7mm 7mm
Presser
foot
lift height
Hand 5.5mm(Max.) 5.5mm(Max.) 5.5mm(Max.)
Knee 13mm(Max.) 13mm(Max.) 13mm(Max.)
Needle DB x 1 #9~#18 DB x 5 #16~#23 DB x 5 #16~#23
Lubrication oil 10# White Oil 10# White Oil 10# White Oil
Motor power 220V / 550W 220V / 550W 220V / 550W
-12-
