12
4-9. Thread Stand
1) Install the thread stand① on the table as in the figure.
[ Fig. 10]
①
4-10. Knee Lifting Pad
1) Attach the knee lifting pad① to the bottom of the oil fan
as in the figure, and fasten it using the bolt②.
2) Loosen the bolt③ to adjust the position of the knee
lifting pad① for user's comfortable operation.
[ Caution ]
When oil supply is completed, do not plug in the sewing machine. When the sewing machine is plugged in, and the pedal is
accidentally stepped on, the sewing machine might start, causing injuries.
When dealing with lubricant, wear glasses and gloves to protect eyes and hands. Take caution not to make eyes and skin
contact lubricant. When lubricant is touched, rinse off the smear with a soap and running water. When lubricant touches
eyes, rinse off lubricant in running water and go to hospital to see a doctor.
Do not swallow lubricant. It may cause diarrhea and vomiting. If you swallow lubricant, immediately see a doctor.
Keep lubricant out of reach of children and youth. Keep lubricant stored away from fire.
4-11. Oil Supply
When it is first time to operate the sewing machine or it is reuse of the sewing machine after a long-term storage, please
supply oil to the machine.
Use original Sunstar lubricant (Lubricant is in the accessory box).
A. Installation of Magnet Removing Chips (Iron Powder)
Attach the magnet removing chips (iron powder), which is inside the accessory box, to the oil pump inside the bed.
※ Do not remove the magnet to use it for other purpose. If the sewing machine is operated without the magnet, it may
cause malfunction in the machine and negatively affect durability of the machine.
[ Fig. 11 ]
①
②
③
To Next Page
