14
C. Install the thread stand on the table.
[ Fig. 9 ]
[ Fig. 7 ]
A. Attach the motor cover on the back side of the machine
(4 positions) by using the 4 joint screws.
4) The Assembly of Peripheral Parts
[ Fig. 8 ]
B. Attach the safety plate to the left side of machine by using
fixing bolt.
Motor Cover
Fixing Screw
Face Plate
Safety Plate
Ass’y
For safety, motor cover and safety plate should be attached to the machine.
Caution
To Next Page
