[ Fig. 10 ]

A. Assembly method of filter regulator attach to right side

of the table leg by using a bolt as shown in the figure.

[ Fig. 11 ]

5) Installation Method of Air Pressure Specifications

B. Assembly method of solenoid valve

Fix it tightly at the proper location of the table bottom by

using the fixing screw.
