5
6. How to Repair the Machine 24
1) Adjusting the Height of the Needle Bar 24
2) Adjusting the Needle and the Shuttle 24
3) Adjusting the Lower Shaft Gear and the Rocking Shaft Gear 25
4) Adjusting the Position of Shuttle Upper Spring 25
5) Adjusting the Height of the Feed Plate 26
6) Adjusting the Height of the Presser Foot Devices 26
7) Adjusting the Presser Foot Devices 26
8) Adjusting the Parts for Thread Release 28
9) Adjusting the Wiper Parts 30
10) Adjusting the Parts for Trimming 31
11) Adjusting the Devices for Main Thread Adjustment 33
12) Adjusting the Winder Devices 33
13) Adjusting the Hand Pulley Device 34
14) Mounting the Direct Motor and Adjusting Method 34
15) Setting Up the X-Y Origin 35
7. Cause of Breakdown and Troubleshooting 36
1) Machine Part 36
8. Pattern List 37
9. Drawing of Table 39
10. Gauge List 40
11. Pneumatic Diagram 43
1) Drawing of the Pneumatic Hose of SPS/D-B1254
A-20, SPS/D-B1263
A-20 Machine
(for Monolithic Feed Frame)
43
2) Drawing of the Pneumatic Hose of SPS/D-B1254
A-22, SPS/D-B1263
A-22 Machine
(for Separately Driven Feed Frame)
44
