Cabling Issues
Cables heat up
This can be caused by a wiring or connection issue. Check the following:
 Check if all cable connections are tightened with a torque moment of 14Nm.
 Check if all fuse connections are tightened with a torque moment of 14Nm.
 Check if the surface area of the cable core is large enough for the current through that cable.
 Check if all cable lugs have been crimped correctly and are tight enough.
WARRANTY
This product has a 5 year limited warranty. This limited warranty covers defects in materials and
workmanship in this product and lasts for ve years from the date of original purchase of this product. To
claim warranty the customer must return the product together with the receipt of purchase to the point of
purchase. This limited warranty does not cover damage, deterioration or malfunction resulting from
alteration, modication, improper or unreasonable use or misuse, neglect, exposure to excess moisture, re,
improper packing, lightning, power surges, or other acts of nature. This limited warranty does not cover
damage, deterioration or malfunction resulting from repairs attempted by anyone unauthorised by Sunsynk
to make such repairs. Non-compliance with the instructions in this manual will render the warranty void.
Sunsynk is not liable for any consequential damages arising from the use of this product. The maximum
liability of Sunsynk under this limited warranty shall not exceed the actual purchase price of the product.
TECHNICAL SPECIFICATIONS
Power
Voltage Range 9 - 50Vdc
Current Rating 800A
Connections
Busbar M8
Physical
Enclosure Material ABS
Enclosure Dimensions (HxWxD) 165x245x75mm
Unit Weight 1.8kg
Busbar Material Tinned Copper
Busbar Dimensions (HxW) 8x30mm
Environmental
Operating Temperature Range -40°C to +60°C
Storage Temperature Range -40°C to +60°C
Humidity Max. 95% (Non-condensing)
Protection Class IP22
