X10SBA/X10SBA-L User’s Manual
SMBUS1 (JSMB1) 4-Pin External System Management Bus I
2
C Header (JSMB1)
SP1 Internal Speaker/Buzzer
USB 0 Backpanel USB 3.0 Port 1
USB 1 Backpanel USB 2.0 Port 2
USB 2/3 Front Accessible USB 2.0 Connections: USB 2, USB 3 (USB 3:
Only available on the X10SBA-L)
USB 4/5 Front Accessible USB 2.0 Connections: USB 4/5 (Only available on
the X10SBA)
USB 6 Type A USB 2.0 Connector: USB 6 (Only available on the X10SBA)
VGA Backpanel VGA Port
X10SBA/X10SBA-L LED Indicators
LED Description Color/State Status
LED1 Main Power LED Green: On Power On
LED5 Standby Power LED Green: On AC On
