Preface
Preface
This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use of the
X10SBA/X10SBA-L motherboard.
About This Motherboard
The X10SBA/X10SBA-L supports the next-generation Intel
®
Celeron
J1900 SoC (System on a Chip) 22nm Quad-Core processor in the BGA 1170 format.
With a 64-bit, 22nm, low-power Tri-gate Quad Core Silvermont processor built into
it, the X10SBA(-L) motherboard offers unprecedented enhancements in system
performance, power efciency, and visual/media capability. This motherboard is
ideal for SMB entry-level Storage, Server, or Appliance platforms that are optimized
for networking, thin-client, Kiosk, Digital Signage, and control-box applications.
Please refer to our website (http://www.supermicro.com/products/) for processor
and memory support updates. This product is intended to be installed and serviced
by professional technicians.
Manual Organization
Chapter 1 describes the features, specications and performance of the mother-
board, and provides detailed information on the Intel Celeron Bay Trail processor
platform.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble-
shooting procedures for video, memory and system setup stored in the CMOS.
Chapter 4 includes an introduction to the BIOS, and provides detailed information
on running the CMOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists software program installation instructions.
Appendix C contains UEFI BIOS Recovery instructions.
