Super X10SBA - Motherboard Features Overview

Chapter 1: Introduction
1-7
Motherboard Features
CPU Single Intel® J1900 SoC (System on a Chip) 64-bit, 22nm
Low-Power, Quad-Core processor in the BGA 1170 format
Memory Supports up to 8 GB of 204-Pin Unbuffered DDR3L (Low
Voltage), Non-ECC, SO-DIMM 1.35V modules of up to
1333 MHz in two horizontal sockets
Note: This motherboard supports 1.35V memory only. Install
the memory modules on the SO-DIMM1 socket rst.
Dual-channel memory
DIMM Size: 2 GB, 4 GB
Expansion Slots One (1) PCI Express 2.0 x2 in x8 slot (Slot 1)
One (1) mini-PCI Express Slot (J1) (for mini-PCI-E only)
One (1) mSATA Slot MUX with a SATA 2.0 Port (J2)
Note: mSATA MUX support is available only when I-SATA1 is not in
use. J2 and I-SATA1 cannot be used together.
Network Connections Two (2) Intel i210AT Gigabit Ethernet Controllers
Two (2) RJ-45 rear I/O panel connectors with Link and
Activity LEDs (LAN1/LAN2)
I/O Devices SATA Connections
SATA 2.0 (3 Gb/s) Two (2) I-SATA 0/1 (Optional Power
Source)
SATA 3.0 (6 Gb/s) Four (4) M-SATA 0-3 (not available on
the -L model)
RAID 0, 1, 10 (MS Windows
®
)
USB Devices
One (1) USB 3.0 port on the rear I/O panel (USB 0)
One (1) USB 2.0 port on the rear I/O panel (USB 1)
Four (4) Front Accessible USB 2.0 ports on two headers
(USB 2/3, 4/5), (USB 3: only available on the X10SBA-L,
USB 4/5: Not available on the L model)
One (1) Type A USB 2.0 connector (USB 6: not available
on the L model)
Serial (COM) Ports
Four (4) front accessible Serial Port header (COM1-
COM4)
One (1) mini-PCI-Express socket (J1)
One (1) mSATA socket (J2) (J2 is not available on the
L-Model; J2 support is available only when I-SATA1 is not
in use)
