1-8
X10SBA/X10SBA-L User’s Manual
Video
One (1) High Denition Multimedia Interface (HDMI) , One
(1) DisplayPort, and One (1) VGA on the back panel
One (1) eDP connector (not available on the L model)
Audio
One (1) HDMI and one (1) DisplayPort on the back panel
One (1) Front panel dual-channel Audio Connector
One (1) S/PDIF Digital Output Header
Super I/O
Nuvoton W83527HG
BIOS 64 Mb AMI BIOS
®
SPI Flash BIOS
Plug and Play, ACPI 5.0, USB Keyboard, SMBIOS 2.7,
UEFI 2.3.1, RTC (Real Time Clock) Wakeup, BIOS Hotkey
Rescue,
Power Conguration ACPI/ACPM, Power Management with S0, S3, S4, S5
support
Main Switch Override Mechanism
Keyboard Wake-up from Soft-Off
External Modem Ring-On
Power-on mode for AC power recovery
PC Health Monitoring System Monitoring
CPU/System overheat LED and control
CPU Thermal Trip support
Fan Control
Fan status monitoring with rmware 4-pin fan speed
control
Low noise fan speed control
System temperature monitor
System Management System resource alert via SuperDoctor® 5
SuperDoctor® 5, Watch Dog/NMI
Power-On mode for AC power recovery
CD Utilities BIOS ash upgrade utility
Other ROHS (Full Compliance, Lead Free)
Operating Temperature: 0-60C
Dimensions Micro-ITX form factor (6.70" x 6.70") (170.18 mm x 170.18
mm)
