19-38 C D/B O’ M
Fig. 16B Trim about 3” from end of cut taper.
Fig. 16D Insert tapered end into outboard slot.
Fig. 16F Mark strip where it crosses drum edge.
Fig. 16H Allow room inside slot for strip to move.
Fig. 16C Trimmed tapered end ready to install.
Fig. 16E Wrap strip around drum without overlap.
Fig. 16G Insert tapered end into inboard slot.
Fig. 16I Reset take-up as needed as strip stretches.
