4-1
Chapter 4: System Interface
Chapter 4
System Interface
4-1 Overview
There are several LEDs on the control panel as well as others on the drive carriers
to keep you constantly informed of the overall status of the system as well as the
activity and health of specic components. This chapter covers these buttons, and
explains the meanings of all LED indicators and the appropriate responses you
may need to take.
Figure 4-1. Chassis Control Panel
Note: Your control panel may differ from the control pan-
el pictured above. See the following pages for further information
