Supermicro SC815 series User Manual

Chapter 1
Introduction
1-1 Overview
Supermicro’s SC815 1U chassis features a unique and highly-optimized design.
The chassis is equipped with a high efciency power supply. High performance fans
provide ample optimized cooling for FB-DIMM memory modules and four hot-swap
drive bays offer maximum storage capacity in a 1U form factor.
1-2 Shipping List
Please visit the following link for the latest shipping lists and part numbers for your
particular chassis model http://www.supermicro.com
Chapter 1: Introduction
1-1
SC815 Chassis
Model HDD I/O Slots
Power
Supply
SC815T-563(CB)(UB)
4x SAS/SATA
CB: 1x FF
UB: 1 FH UIO:
1x FF, 1x LP
560W (Gold Level)
SC815T-330(CB)(UB)
4x SAS/SATA
CB: 1x FF
UB: 1 FH UIO:
1x FF, 1x LP
330W (Gold Level)
SC815TQ-720(CB)(UB)
4x SAS/SATA
CB: 1x FF
UB: 1 FH UIO:
1x FF, 1x LP
700W (Gold Level)
SC815TQ-710(U)(B)
4x SAS/SATA
1 FH UIO:
1x FF, 1x LP
710W DC
SC815TQ-R706WB
4x SAS/SATA 1 WIO: 2x FF, 1x LP
750W Redundant
(Platinum Level)
SC815TQ-R700
(CB)(UB)(WB)
4x SAS/SATA
WB: 1 WIO:
2x FF, 1x LP
CB: 1x FF
UB: 1 FH UIO:
1x FF, 1x LP
700W Redundant
SC815TQ-R654CB
4x SAS/SATA 1x FF
650W DC
Redundant

Supermicro SC815 series Specifications

General

Brand	Supermicro
Model	SC815 series
Category	Chassis
Language	English
